Doc ID : ADR111A_IM_01
Ref ID : ADR111A/IM/UG
Rev No. : 04
ADR111A /
ADR211A
The setting range is 5 to 250% in steps of 1%.
Press the left arrow Key () to move to the next option.
I> TMS = x1.000
Range x0.01 – 1.50
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired I> TMS (Time Multiplier Settings)
can be set.
The setting range is x0.01 to 1.50 in steps of 0.005
Press the left arrow Key () to move to the next option.
I>> = 0100
Range 50 – 3000%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired I>> can be set.
The setting range is 50% to 3000% in steps of 1%
Press the left arrow key () to move to the next option.
I> Curve = C1
Range C1 – C6
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired I> Curve (IDMT Curve) can be
selected.
Seven different types of curves are provided C1 to C6. When
the given value is C1 curve 1 is selected and when the given
value is C2 curve 2 is selected. In similar manner any desired
curve can be selected as C1 to C6 corresponds
C1 = Normal Inverse 1 (10 Times 3.0 sec)
C2 = Normal Inverse 2 (10 Times 1.3 sec)
C3 = Very Inverse (10 Times 1.5 sec)
C4 = Extremely Inverse (10 Times 0.8 sec)
C4A = Extremely Inverse (10 Times 0.6 sec)
C5 = Long Time Inverse (10 Times 13.3 sec)
C6 = Definite Time (Inst. to 99.9 sec)
Press the left arrow Key () to move to the next option.
