I>C6 Time = 00.1
Range 00 – 99.9 S
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired I>C6 Time (Definite Time Delay)
can be set.
The setting range is 00 to 99.9 S in steps of 0.1 S. This setting
is effective only when C6 curve is selected.
Press the left arrow Key () to move to the next option.
I>> Delay = 00.05
Range 0 – 10.00 S
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired I>> Delay can be set.
The setting range is 0 to 10.00 S in steps of 0.01 S.
Press the left arrow Key () to move to the next option.
BF Delay = 100
Range 00 – 800 ms
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired BF Delay (Breaker Fail) can be
set.
The setting range is 00 to 800 ms in steps of 50 ms.
The 000
means bypass this feature.
Press the left arrow Key () to move to the next option.
CT Sec. = 001
1 = 1A, 2 = 5A
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CT Secondary can be selected.
i.e. 1 or 2. In which, 1 corresponds with 1 Amp. and 2
correspond with 5 Amp respectively.
Press the left arrow Key () to move to the next option.
CT Primary = 0010
Range 10 – 5000
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired CT Primary can be set.
The Setting Range is from 10 to 5000A in steps of 1A. (For
example suppose CT Ratio is 500/1A then you have to select
