Servicemanual TD60
30
Technical data TD60
Height: 850 mm
Width: 595 mm
Depth: 585 mm
Weight: 39kg (vented)
47 kg (condenser)
Cylinder volume: 111 l
Max. loading capacity: Eu 7.0 kg, US, AU 6.0 kg
RPM: 52 rpm
Rated power: 1950 W = 10 A
2500 W = 16 A
Adjustment between 10 and 16 A is carried out using software via
buttons.
Drying drum material: Stainless steel
Outer casing material: Powder-coated and hot-galvanized sheet steel or stainless steel
Set-up: Stacking or freestanding
Protection class: IP X4
