Asko TD60 - Timer Diagram; TD60 Program Flow Description

Servicemanual TD60
38
Start
Components
Step times
Program Option Anti crease
Cool-down
Table explanation
Option
Buzzer
3'' on, 57'' off
3' - 15'
3''
Air fluff Auto program Time program
Timer diagram (description of program flow) TD60
Motor
2'
Drain pump (30 sec. on, 210 sec. off) Heater Buzzer
Drying sequence (max 3 hours)
20 minutes - 2 hours
5 minutes - 2 hours
Appendix: Timer diagram
80 813 77 Rev 05 Service manual TD60 EN
Timerdiagram
