51
For Manual Offset, use the Numeric keys to enter the m Offset value and then press the
ENTER key. The program will store the m Offset setting and advance to the Connect
setting. The range of m Offset is from 0 to 200 m. The unit is m and 1m per step.
For Auto Offset, setup the test parameter of Output Voltage, Current and Frequency and
connect the test cables and/or test fixture to the instrument first. Then short circuit the
ends of the test cables. If the scanner is being used, the scanner channel has to be set.
Then press the TEST button. The program will activate the test current and frequency
that has been set for this memory-step. The display will show:
Offset = XXX m
TEST to Auto Set
The display will show the measured m Offset value and the program will use this value
for the Offset setting. Each step has its own individual Offset value and must be set
separately. This allows the user to compensate for different lead lengths when using a
scanner or external fixturing for Ground Bond testing.
Then press the or key to advance the program to another test parameter setting or
press the EXIT key to exit from the setting mode to operation mode.
Step Connection setting
Advance the menu to the Connection parameter. The display will show:
Connect = ON
ENTER to Select
Connect = OFF
ENTER to Select
Use the ENTER key to select the Step Connection mode, then press the or key to
advance the program to another test parameter or press the EXIT key to exit from the
setting mode to the operation mode.
If Connect is set to ON, the next step in the sequence will be executed. If Connect is set
to OFF, the test sequence will stop at this step.
If Step 8 is set to ON the test process will be connected to the first step of the next
Memory.
