If the test in process is Aborted with the RESET button or remote control before the
meter readings are taken, the display will show:
DCW Abort XXX.X s
MXX-X - . - - KV - - - - A
or
DCW Abort XXX.X s
MXX-X X.XX KV - - - - A
At the beginning of DC Withstand Voltage test when the voltage begins to ramp but
before the meter readings are taken, the display will show:
DCW Ramp XXX.X s
MXX-X - . - - KV - - - - A
During the DC Withstand Voltage test when the values are being updated in real time
during the Ramp cycle, the display will show:
DCW Ramp XXX.X s
MXX-X X.XX KV XXXX A
During the DC Withstand Voltage test when the values are being updated in real time
during the Dwell cycle, the display will show:
DCW Dwell XXX.X s
MXX-X X.XX KV XX.XX A
If the Ramp time is very short and the program has not read the meter readings, the
display will show:
DCW Dwell XXX.X s
MXX-X - . - - KV - - - - A
If the Ramp-HI function is enabled and the leakage current during the Ramp cycle
exceeds 10mA, then the display will show:
DCW Ramp-HI XXX.X s
MXX-X X.XX KV >9999 A
If the leakage current during the Ramp cycle falls below the Charge -LO setting, then the
display will show:
DCW Charge-LO XXX.X s
MXX-X X.XX KV XXX.X. A

Associated Research 7704 Specifications

General

Voltage Range	0 - 5 kV AC, 0 - 6 kV DC
Frequency Range	50/60 Hz
Display Type	LCD
Power Supply	100 - 240 VAC, 50/60 Hz
Safety Standards	UL, CSA, CE
AC Hipot Voltage	5 kV AC
DC Hipot Voltage	6 kV DC
Insulation Resistance	1 MΩ - 50 GΩ
Resistance Range	1 MΩ - 50 GΩ
