63
If the DUT current exceeds the HI-Limit of DC Withstand Voltage test and the leakage
current is within the metering range, the display will show:
DCW HI-Limit XXX.X s
MXX-X X.XX KV XXXX A
If the DUT current exceeds the HI-Limit of DC Withstand Voltage test and the leakage
current is not within the metering range, the display will show:
DCW HI-Limit XXX.X s
MXX-X X.XX KV 9999 A
If the DUT current is well beyond the metering range of DC Withstand Voltage test the
instrument assumes that the failure is due to a short circuit, the display will show:
DCW Short XXX.X s
MXX-X - . - - KV 9999 A
If the DUT current is well beyond the metering range of DC Withstand Voltage test and
an Arcing condition beyond the Arc Sense limit is indicated, the display will show:
DCW Breakdown XXX.X s
MXX-X X.XX KV 9999 A
If the DUT current falls below the LO-Limit of DC Withstand Voltage test and the
leakage current is within the metering range, the display will show:
DCW LO-Limit XXX.X s
MXX-X X.XX KV XXX.X A
If the DUT current within the metering range of the DC Withstand Voltage test and an
Arcing current exceeds the Arc-Sense limit and the Arc functions is set to ON then an
Arc failure has occurred and the display will show:
DCW Arc-Fail XXX.X s
MXX-X X.XX KV XX.X A
If the GFI threshold is exceeded during of the DC Withstand Voltage test, the display will
show:
DCW GND-Fault XXX.X s
MXX-X X.XX KV XXXX A
