OMNIBUS II PXIE SPECIFIC FEATURES
Refer to Table 5.3 for mappings between protocol syncs (Sync A-C) and PXIe
Triggers (PXI*).
Protocol Trigger
PXIe Signal
Trigger Mask Parameter
A
PXI_TRIG[0]
TRIGMASK_PXITRIGA
PXIe_DSTARA
TRIGMASK_PXISTARA
B
PXI_TRIG[1]
TRIGMASK_PXITRIGB
PXIe_DSTARB
TRIGMASK_PXISTARB
C
PXI_TRIG[2]
TRIGMASK_PXITRIGC
PXI_STAR
TRIGMASK_PXISTARC
Table 5.2—PXIe Trigger to Protocol Trigger Mapping
Protocol Sync
PXIe Signal
Sync Mask Parameter
A
PXI_TRIG[0]
SYNCMASK_PXITRIGA
B
PXI_TRIG[1]
SYNCMASK_PXITRIGB
C
PXI_TRIG[2]
SYNCMASK_PXITRIGC
PXI_STAR
SYNCMASK_PXISTARC
Table 5.3—PXIe Trigger to Protocol Sync Mapping
Triggers are mutually exclusive; however, syncs are not. For example, only
PXI_TRIG[0] or PXIe_DSTARA can be configured at one time to trigger the
protocol logic; however, the protocol logic can drive the sync out to both
PXI_TRIG[2] and PXI_STAR at the same time.
OmniBus II PCIe/PXIe User’s Manual 5-3
