OMNIBUS II PXIE SPECIFIC FEATURES
The OmniBus II PXIe also extends the protocols’ TriggerDefine function
capabilities by adding transitional trigger parameters. These new parameters
allow the protocol to be triggered on a high, low, rising, or falling state of the
assigned protocol trigger (A-C). To use this feature, pass the respective
parameter found in
Table 5.4 to the pinpolarity argument of the TriggerDefine
function (e.g. BTI1553_BCTriggerDefine).
Trigger
API
pinpolarity
Description
A
TRIGPOL_TRIGAL
Sets active low polarity for trigger line A
TRIGPOL_TRIGAH
Sets active high polarity for trigger line A
TRIGPOL_TRIGAF
Sets active on falling edge of trigger line A
TRIGPOL_TRIGAR
Sets active on rising edge of trigger line A
B
TRIGPOL_TRIGBL
Sets active low polarity for trigger line B
TRIGPOL_TRIGBH
Sets active high polarity for trigger line B
TRIGPOL_TRIGBF
Sets active on falling edge of trigger line B
TRIGPOL_TRIGBR
Sets active on rising edge of trigger line B
C
TRIGPOL_TRIGCL
Sets active low polarity for trigger line C
TRIGPOL_TRIGCH
Sets active high polarity for trigger line C
TRIGPOL_TRIGCF
Sets active on falling edge of trigger line C
TRIGPOL_TRIGCR
Sets active on rising edge of trigger line C
Table 5.4—Transitional Protocol Trigger Parameters
5.4 PXIe Status
The OmniBus II PXIe provides access to some useful PXIe card status
information. The desired status is selected by passing in one of the parameters
found in Table 5.5 to infotype in BTICard_PXIStatus.
infotype
infoptr
PXITYPE_GEOADDR
Geographical Address
PXITYPE_CLKSEL
PXIe Clock Selection (Refer to Section 5.1)
0 = PXIe_CLK100
1 = On-Board 100MHz Oscillator
PXITYPE_TRIGVERS
Version of the BTI PXIe Trigger Engine
PXITYPE_OUTEN
Bitmask of Output Enables for dionums 33 to 48
(Refer to Section 5.3 for more information)
Table 5.5—PXIe Status Parameters
