Astronics OmniBusII - Mil-Std-1553; Table 7.2-Pinouts for MIL-STD-1553 Modules

CONNECTOR PINOUTS
7.3.1 MIL-STD-1553
The pin assignments for the MIL-STD-1553 modules are listed in Table 7.2 be-
low. Be sure to follow the coupling and termination guidelines provided in
Appendix A.
Used on Modules
Name Description
LFH
Pair #
LFH
Pin
16036
Pin
LFH
Name
5x0
5x1 to 5x5
CH0 CH0
CH0AD
BUS A direct coupled (+)
14
28
P2-2
BUS1P
CH0ADR
BUS A direct coupled (–)
14
29
P2-14
BUS1N
CH0AX
BUS A transformer coupled (+)
1
3
P2-3
BUS0P
CH0AXR BUS A transformer coupled (–) 1 2 P2-15 BUS0N
CH0BD
BUS B direct coupled (+)
2
5
P2-4
BUS2P
CH0BDR
BUS B direct coupled (–)
2
4
P2-16
BUS2N
CH0BX
BUS B transformer coupled (+)
13
26
P2-5
BUS3P
CH0BXR
BUS B transformer coupled (–)
13
27
P2-17
BUS3N
n/a CH1
CH1AD
BUS A direct coupled (+)
29
58
P3-2
BUS9P
CH1ADR
BUS A direct coupled (–)
29
59
P3-14
BUS9N
CH1AX
BUS A transformer coupled (+)
16
33
P3-3
BUS8P
CH1AXR
BUS A transformer coupled (–)
16
32
P3-15
BUS8N
CH1BD
BUS B direct coupled (+)
17
35
P3-4
BUS10P
CH1BDR
BUS B direct coupled (–)
17
34
P3-16
BUS10N
CH1BX
BUS B transformer coupled (+)
28
56
P3-5
BUS11P
CH1BXR
BUS B transformer coupled (–)
28
57
P3-17
BUS11N
Avionics DIOs
ADIO0
Avionics DIO 0
3
7
BUS4P
ADIO1
Avionics DIO 1
3
6
BUS4N
ADIO2
Avionics DIO 2
12
24
BUS5P
ADIO3
Avionics DIO 3
12
25
BUS5N
ADIO4
Avionics DIO 4
4
9
BUS6P
ADIO5
Avionics DIO 5
4
8
BUS6N
ADIO6
Avionics DIO 6
11
22
BUS7P
ADIO7
Avionics DIO 7
11
23
BUS7N
ADIO8
Avionics DIO 8
18
37
BUS12P
ADIO9
Avionics DIO 9
18
36
BUS12N
ADIO10
Avionics DIO 10
27
54
BUS13P
ADIO11
Avionics DIO 11
27
55
BUS13N
ADIO12
Avionics DIO 12
19
39
BUS14P
ADIO13
Avionics DIO 13
19
38
BUS14N
ADIO14
Avionics DIO 14
26
52
BUS15P
ADIO15
Avionics DIO 15
26
53
BUS15N
Table 7.2—Pinouts for MIL-STD-1553 modules
OmniBus II PCIe/PXIe User’s Manual 7-3
