CONNECTOR PINOUTS
7.3.4 ARINC 717
The pin assignments for the ARINC 717 modules are listed in Table 7.5 below.
All ARINC 717 channels can be either biphase or bipolar.
Note: Module 455 in the table below also includes ARINC 429 chan-
nels. See
Table 7.3 for pinouts of the 429 channels on this module.
451
4R/4T
455*
4R/4T
Channel
Polarity
LFH
Pair #
LFH
Pin
16036
Pin
LFH
Name
R
(biphase/
bipolar)
R
(biphase/
bipolar)
CH4
+
3
7
P2-6
BUS4P
–
3
6
P2-18
BUS4N
R
(biphase/
bipolar)
R
(biphase/
bipolar)
CH5
+
12
24
P2-8
BUS5P
– 12 25 P2-19 BUS5N
R
(biphase/
bipolar)
R
(biphase/
bipolar)
CH6
+
4
9
P2-9
BUS6P
–
4
8
P2-20
BUS6N
R
(biphase/
bipolar)
R
(biphase/
bipolar)
CH7
+
11
22
P2-10
BUS7P
– 11 23 P2-21 BUS7N
T
(biphase/
bipolar)
T
(biphase/
bipolar)
CH12
+
18
37
P3-6
BUS12P
– 18 36 P3-18 BUS12N
T
(biphase/
bipolar)
T
(biphase/
bipolar)
CH13
+
27
54
P3-8
BUS13P
– 27 55 P3-19 BUS13N
T
(biphase/
bipolar)
T
(biphase/
bipolar)
CH14
+
19
39
P3-9
BUS14P
– 19 38 P3-20 BUS14N
T
(biphase/
bipolar)
T
(biphase/
bipolar)
CH15
+
26
52
P3-10
BUS15P
– 26 53 P3-21 BUS15N
R = receive and T = transmit
* See Table 7.3 for the ARINC 429 pinouts for PN 455
Table 7.5—Pinouts for ARINC 717 modules
