Astronics OmniBusII - Table 7.6-Wiring Chart for 16036 Cable Assembly

CONNECTOR PINOUTS
P2 Pair #
From
P1 pin
To
P2 pin
Name P3 Pair #
From
P1 pin
To
P3 pin
Name
1
3
3
BUS0P
1
33
3
BUS8P
1
2
15
BUS0N
1
32
15
BUS8N
2
28
2
BUS1P
2
58
2
BUS9P
2
29
14
BUS1N
2
59
14
BUS9N
3 5 4 BUS2P 3 35 4 BUS10P
3
4
16
BUS2N
3
34
16
BUS10N
4
26
5
BUS3P
4
56
5
BUS11P
4
27
17
BUS3N
4
57
17
BUS11N
5 7 6 BUS4P 5 37 6 BUS12P
5
6
18
BUS4N
5
36
18
BUS12N
6
24
8
BUS5P
6
54
8
BUS13P
6
25
19
BUS5N
6
55
19
BUS13N
7
9
9
BUS6P
7
39
9
BUS14P
7 8 20 BUS6N 7 38 20 BUS14N
8
22
10
BUS7P
8
52
10
BUS15P
8
23
21
BUS7N
8
53
21
BUS15N
9
11
11
CDIO0
9
41
11
CDIO3
9 10 23 GND 9 40 23 GND
10
17
12
IRIG
10
47
12
RSVD
10
19
24
CDIO5
10
49
24
CDIO6
11
13
13
CDIO4
11
43
13
CDIO7
11 15 25 NC/5V 11 45 25 NC/5V
12
21
22
CDIO1
12
51
22
CDIO2
12
20
1
GND
12
50
1
GND
13
14
7
CGND
13
44
7
CGND
Braids connected shell to shell
Table 7.6—Wiring chart for 16036 cable assembly
