7.4.3 MIL-STD-1553 Cable Assemblies
Ballard offers four standard cable assemblies for MIL-STD-1553 (see Table 7.7
below). The standard length is three feet.
Cable Assy. No. No. of Ch. CH0 CH1 D-Sub
16037 2
  
16038
2
 
–
16039
1

–

16041
1

–
–
Table 7.7—MIL-STD-1553 cable assembly configurations
These four cables are available for single or dual channel modules and with or
without a D-sub connector. All of them provide a twinax cable from the LFH
connector to a PL-75 for each of the transformer coupled MIL-STD-1553 buses.
All channels are dual redundant, so there are either two or four twinax cables
with PL-75s on each assembly. Twinax cables are wired as shown in Table 7.8.
Cable Name
Wire Name
From LFH Pin
To PL-75
LFH Name
CH0 CH0AX 3 Center BUS0P
BUS A
CH0AXR
2
Outer
BUS0N
CH0
CH0BX
26
Center
BUS3P
BUS B CH0BXR 27 Outer BUS3N
CH1
CH1AX
33
Center
BUS8P
BUS A
CH1AXR
32
Outer
BUS8N
CH1
CH1BX
56
Center
BUS11P
BUS B
CH1BXR
57
Outer
BUS11N
Braids connected between the LFH shell and the PL-75 shell
Table 7.8—Twinax wiring on MIL-STD-1553 cable assemblies
