ASUS SABERTOOTH 990FX R3.0
3-13
Chapter 3
CPU & NB Voltage [Offset Mode]
Allows you to set the CPU & NB Voltage Mode. Different sub-items appear according to the
CPU & NB Voltage Mode item setting.
Conguration options: [Offset Mode] [Manual Mode]
The following items appear only when you set CPU & NB Voltage to [Offset Mode].
Offset Mode Sign [+]
This item allows you to set the offset mode sign.
Conguration options: [+] [-]
CPU Offset Voltage [Auto]
This item allows you to set the CPU Offset voltage. Use the <+> or <-> to adjust the
value. The values range from 0.006250V to 0.700000V with an interval of 0.06250V.
CPU/NB Offset Mode Sign [+]
This item allows you to set the offset mode sign.
Conguration options: [+] [-]
CPU/NB Offset Voltage [Auto]
This item allows you to set the CPU/NB Offset voltage. Use the <+> or <-> to adjust the
value. The values range from 0.006250V to 0.700000V with an interval of 0.06250V.
The following item appears only when you set CPU Voltage Frequency to [Manual].
VRM Fixed Frequency Mode [300]
This item allows you to set a higher frequency for a quicker transient
response speed. Use the <+> or <-> to adjust the value. The values range
from 200 KHz to 400 KHz with an interval of 10 KHz.
CPU Power Duty Control [T.Probe]
[T.Probe] Maintains the VRM thermal balance.
[C.Probe Current] Maintains the VRM current balance.
CPU Power Response Control [Auto]
Conguration options: [Auto] [Regular] [Medium] [Fast] [Ultra Fast]
CPU/NB Power Response Control [Auto]
Conguration options: [Auto] [Regular] [Medium] [Fast] [Ultra Fast]
CPU Power Thermal Control [130]
Higher temperature provides a wider CPU power thermal range and extends the
overclocking tolerance to enlarge the overclocking potential.
Conguration options: [130] - [151]

Asus SABERTOOTH 990FX R3.0 Specifications

General

Chipset	AMD 990FX/SB950
CPU Support	AMD AM3+ FX/Phenom II/Athlon II/Sempron 100 Series Processors
CPU Socket Type	AM3+
Storage	6 x SATA 6Gb/s
SATA RAID	RAID 0, 1, 5, 10
Audio	Realtek ALC1150 8-Channel High Definition Audio CODEC
LAN	Intel I211-AT, 1 x Gigabit LAN Controller(s)
Form Factor	ATX
Dimensions	12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Memory Support	4 x DIMM, Max. 32GB, DDR3 1866/1600/1333/1066 MHz, ECC, Non-ECC, Un-buffered Memory
Expansion Slots	1 x PCIe 2.0 x1 1 x PCI
USB Ports	12 x USB 2.0 (6 at back panel, 6 at mid-board)
Power Pin	24-pin ATX Power Connector, 8-pin ATX 12V Power Connector
Multi-GPU Support	Supports NVIDIA Quad-GPU SLI and AMD Quad-GPU CrossFireX Technology
