Trouble on One Voice Terminal
SCREW
CAPS
Figure 20—Removing the Cover from a Jack
CAPS
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
WHITE–BLUE
BLUE
WHITE–ORANGE
ORANGE
WHITE–GREEN
GREEN
WHITE–BROWN
BROWN
Figure 21—103A Modular Jack Wiring
