15
sequence shown below.
Step Action
1 Power up the controller
2 Put the controller in Standby mode
3 If you plan to use a temperature input (thermocouple or RTD) and do not plan to use the
default units of measure Fahrenheit, select the units of measure.
4 Specify the input type. If the input is linear, scale the input.
5 Optional – Specify the number of decimal places to be stored and displayed and the display
defaults.
6
function.
7
cooling only) and deadband (heating and cooling).
For Autotuning, prepare the process and initiate the operation.
8
9
10
the controller detects a problem with the input.
11
remote analog setpoint, or the function of an auxiliary analog output.
12 Adjust the setpoint.
13 Change the security access level to the most restrictive level that is appropriate for your
site.
To Next Page
