4) HID Language : When connected in HID mode, set the keyboard language type. User can
choose from ‘UNIVERSAL’, ‘FRENCH’, ‘UK’ and ‘US’.
5) Notification : Set the action when a button is pressed or in an Alert situation.
• Button Notify : Set whether to operate ‘Beep’, ‘Vibrate’, and ‘Light’ when the button is pressed.
• Alert Notify : Set whether to operate ‘Beep’, ‘Vibrate’, and ‘Light’ in Alert situations such as
booting, scan success, or connection/failure with Remote. The operating time may vary
depending on the situation.
• Button Mode : Select the duration of Button Notify from ‘None’, ‘Short’, or ‘Long’. If set to None,
there is no reaction when the button is pressed, and if set to ‘Short’, it operates for 0.3 seconds.
When set to ‘Long’, it continues to operate until the button is released.
• Bar NR Alert : Set the Barcode Engine reading failure alert among ‘No Alert’, ‘Two short Alt’, and
‘One long Alt’. It works only when ‘Alert Notify → Beep’ Option is enabled.
6) BT HID Delay : Set the delay time when transmitting data to the Host device in Bluetooth HID
Mode. User can select from 3ms, 10ms, 20ms, 30ms, 40ms, 50ms, and 60ms. If there is a problem
with data transmission in Bluetooth HID Mode, please set the Delay longer.
7) Display Mode : Set the data format of UHF Tag Data. The format transmitted to screen and Host
device are changed. If the communication mode is Interactive Mode or the UHF RFID Data Report
setting is set to ‘PC+EPC’, it may not operate normally.
8) Trigger Mode : It sets the method of stopping operation of Barcode or RFID Data Reading Feature.
• STD Start Stop : Pressing the Barcode or RIFD Scan Button activates the function, and releasing
the button stops the function.
• C Button Stop : If user press the Barcode or RIFD Scan Button, the corresponding function
operates, and if user press the Button, the corresponding function stops..
9) Button Hold : In scan mode, determine whether to use adjusting RF power level option by ◀, ▶
button.
7. Config Setup
In this mode, the connection mode is changed so that it is connected through a PC and a USB VCP
(Virtual Serial Port). For the dedicated setting program for PC, please refer to the separately distributed
manual.
