9
AT388 User Guide
3. Product Appearance Left / Right , Top / Bottom
1) Barcode Engine : Barcode engine that can recognize barcode data is located.
2) USB Connector : For charging and data transfer, it can be connected to a PC or a charger by
connecting a Micro USB.
3) Strap Hole : A neck strap or hand strap included with the product can be connected.
4) Protective Cover : When the USB port is not in use, a protective cover is used to protect it from
external contamination.
Strap Hole
Battery Cover
RFID Antenna
Protective
Cover
Barcode Engine
USB Connector
RFID Antenna
Strap Hole
