Settings EN MT Focus 6000
10
© Atlas Copco Industrial Technique AB - 9839 0527 01
A Current progress. If no verification size is set, an infin-
ity symbol is display.
B Reference torque.
C Torque from tightening controller (only available if veri-
fication is run through USB Sync.
D Deviation from target (only available if there is a tar-
get).
E Result status: Green = OK; Red = NOK.
F Sequence number.
G Target torque.
H Average reference torque.
I Average tightening torque.
J Cmk control limit.
K Cmk.
L Average deviation from target.
Tightening
Description
Select Pset A list of the available Psets.
Select V. Program A list of the available verification programs.
Quick programming Create a Pset or a verification program.
Start tightening Starts the active Pset.
Stop tightening Stops the rotation of the tool.
Quick programming
To use quick programming perform the following steps:
1. Select Tightening in the first page menu.
2. Select Quick programming.
3. Select which tightening program to create, Pset or Verification program
4. Select the desired parameter to edit the value.
5. Use the up and down arrows to increment/decrement the values.
6. Scroll down and press Save settings.
Quick programming will save to an available Pset number. If no Pset number is available, you must
delete an old Pset to save a new one.
Batch sequence
Batch sequences are used to perform a specified number of tightening, event and information steps in a
specific order.
Description
Select Batch sequence Select a Batch sequence.
Reset Batch Resets the current batch.
