426

8025I–AVR–02/09

ATmega48P/88P/168P/328P

(0xC1) UCSR0B RXCIE0 TXCIE0 UDRIE0 RXEN0 TXEN0 UCSZ02 RXB80 TXB80 196

(0xC0) UCSR0A RXC0 TXC0 UDRE0 FE0 DOR0 UPE0 U2X0 MPCM0 195

(0xBF) Reserved – – – – – – – –

(0xBE) Reserved – – – – – – – –

(0xBD) TWAMR TWAM6 TWAM5 TWAM4 TWAM3 TWAM2 TWAM1 TWAM0 –244

(0xBC) TWCR TWINT TWEA TWSTA TWSTO TWWC TWEN –TWIE 241

(0xBB) TWDR 2-wire Serial Interface Data Register 243

(0xBA) TWAR TWA6 TWA5 TWA4 TWA3 TWA2 TWA1 TWA0 TWGCE 244

(0xB9) TWSR TWS7 TWS6 TWS5 TWS4 TWS3 –TWPS1TWPS0 243

(0xB8) TWBR 2-wire Serial Interface Bit Rate Register 241

(0xB7) Reserved – – – – – – –

(0xB6) ASSR – EXCLK AS2 TCN2UB OCR2AUB OCR2BUB TCR2AUB TCR2BUB 164

(0xB5) Reserved – – – – – – – –

(0xB4) OCR2B Timer/Counter2 Output Compare Register B 162

(0xB3) OCR2A Timer/Counter2 Output Compare Register A 162

(0xB2) TCNT2 Timer/Counter2 (8-bit) 162

(0xB1) TCCR2B FOC2A FOC2B

– – WGM22 CS22 CS21 CS20

161

(0xB0) TCCR2A COM2A1 COM2A0 COM2B1 COM2B0

– –WGM21WGM20 158

(0xAF) Reserved – – – – – – – –

(0xAE) Reserved

– – – – – – – –

(0xAD) Reserved

– – – – – – – –

(0xAC) Reserved – – – – – – – –

(0xAB) Reserved – – – – – – – –

(0xAA) Reserved – – – – – – – –

(0xA9) Reserved – – – – – – – –

(0xA8) Reserved – – – – – – – –

(0xA7) Reserved – – – – – – – –

(0xA6) Reserved – – – – – – – –

(0xA5) Reserved – – – – – – – –

(0xA4) Reserved – – – – – – – –

(0xA3) Reserved – – – – – – – –

(0xA2) Reserved – – – – – – – –

(0xA1) Reserved – – – – – – – –

(0xA0) Reserved – – – – – – – –

(0x9F) Reserved – – – – – – – –

(0x9E) Reserved – – – – – – – –

(0x9D) Reserved – – – – – – – –

(0x9C) Reserved – – – – – – – –

(0x9B) Reserved – – – – – – – –

(0x9A) Reserved – – – – – – – –

(0x99) Reserved – – – – – – – –

(0x98) Reserved – – – – – – – –

(0x97) Reserved – – – – – – – –

(0x96) Reserved

– – – – – – – –

(0x95) Reserved

– – – – – – – –

(0x94) Reserved – – – – – – – –

(0x93) Reserved

– – – – – – – –

(0x92) Reserved

– – – – – – – –

(0x91) Reserved

– – – – – – – –

(0x90) Reserved – – – – – – – –

(0x8F) Reserved

– – – – – – – –

(0x8E) Reserved

– – – – – – – –

(0x8D) Reserved – – – – – – – –

(0x8C) Reserved

– – – – – – – –

(0x8B) OCR1BH Timer/Counter1 - Output Compare Register B High Byte 138

(0x8A) OCR1BL Timer/Counter1 - Output Compare Register B Low Byte 138

(0x89) OCR1AH Timer/Counter1 - Output Compare Register A High Byte 138

(0x88) OCR1AL Timer/Counter1 - Output Compare Register A Low Byte 138

(0x87) ICR1H Timer/Counter1 - Input Capture Register High Byte 139

(0x86) ICR1L Timer/Counter1 - Input Capture Register Low Byte 139

(0x85) TCNT1H Timer/Counter1 - Counter Register High Byte 138

(0x84) TCNT1L Timer/Counter1 - Counter Register Low Byte 138

(0x83) Reserved – – – – – – – –

(0x82) TCCR1C FOC1A FOC1B – – – – – –137

(0x81) TCCR1B ICNC1 ICES1

– WGM13 WGM12 CS12 CS11 CS10 136

(0x80) TCCR1A COM1A1 COM1A0 COM1B1 COM1B0

– –WGM11WGM10 134

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
