84
7598H–AVR–07/09
ATtiny25/45/85
14.1.1 Timer/Counter1 Control Register - TCCR1
• Bit 7- CTC1 : Clear Timer/Counter on Compare Match
When the CTC1 control bit is set (one), Timer/Counter1 is reset to $00 in the CPU clock cycle
after a compare match with OCR1C register value. If the control bit is cleared, Timer/Counter1
continues counting and is unaffected by a compare match.
• Bit 6- PWM1A: Pulse Width Modulator A Enable
When set (one) this bit enables PWM mode based on comparator OCR1A in Timer/Counter1
and the counter value is reset to $00 in the CPU clock cycle after a compare match with OCR1C
register value.
• Bits 5,4 - COM1A1, COM1A0: Comparator A Output Mode, Bits 1 and 0
The COM1A1 and COM1A0 control bits determine any output pin action following a compare
match with compare register A in Timer/Counter1. Output pin actions affect pin PB1 (OC1A).
Since this is an alternative function to an I/O port, the corresponding direction control bit must be
set (one) in order to control an output pin. Note that OC1A
is not connected in normal mode.
In PWM mode, these bits have different functions. Refer to Table 14-4 on page 90 for a detailed
description.
• Bits 3 .. 0 - CS13, CS12, CS11, CS10: Clock Select Bits 3, 2, 1, and 0
The Clock Select bits 3, 2, 1, and 0 define the prescaling source of Timer/Counter1.
Bit 7 6 5 4 3 2 1 0
$30 ($50)
CTC1 PWM1A COM1A1 COM1A0 CS13 CS12 CS11 CS10 TCCR1
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
Table 14-1. Comparator A Mode Select
COM1A1 COM1A0 Description
0 0 Timer/Counter Comparator A disconnected from output pin OC1A.
0 1 Toggle the OC1A output line.
1 0 Clear the OC1A output line.
1 1 Set the OC1A output line
Table 14-2. Timer/Counter1 Prescale Select
CS13 CS12 CS11 CS10
Asynchronous
Clocking Mode
Synchronous
Clocking Mode
0 0 0 0 T/C1 stopped T/C1 stopped
0001PCK CK
0 0 1 0 PCK/2 CK/2
0 0 1 1 PCK/4 CK/4
0 1 0 0 PCK/8 CK/8
0 1 0 1 PCK/16 CK/16
0 1 1 0 PCK/32 CK/32
