26.9 External Data Memory Characteristics
Notes: 1. This assumes 50% clock duty cycle. The half period is actually the high time of the external clock, XTAL1.
2. This assumes 50% clock duty cycle. The half period is actually the low time of the external clock, XTAL1.
Table 26-7. External Data Memory Characteristics, V
CC
= 4.5 - 5.5 Volts, No Wait-state
Symbol Parameter
8 MHz Oscillator Variable Oscillator
Unit
Min. Max. Min. Max.
01/t
CLCL
Oscillator Frequency 0.0 16 MHz
1t
LHLL
ALE Pulse Width 115 1.0 t
CLCL
– 10 ns
2t
AVLL
Address Valid A to ALE Low 57.5 0.5 t
CLCL
– 5
(1)
ns
3a t
LLAX_ST
Address Hold After ALE Low,
write access
55 ns
3b t
LLAX_LD
Address Hold after ALE Low,
read access
55 ns
4t
AVLLC
Address Valid C to ALE Low 57.5 0.5 t
CLCL
– 5
(1)
ns
5t
AVRL
Address Valid to RD Low 115 1.0 t
CLCL
– 10 ns
6t
AVWL
Address Valid to WR Low 115 1.0 t
CLCL
– 10 ns
7t
LLWL
ALE Low to WR Low 47.5 67.5 0.5 t
CLCL
– 15
(2)
0.5 t
CLCL
+ 5
(2)
ns
8t
LLRL
ALE Low to RD Low 47.5 67.5 0.5 t
CLCL
– 15
(2)
0.5 t
CLCL
+ 5
(2)
ns
9t
DVRH
Data Setup to RD High 40 40 ns
10 t
RLDV
Read Low to Data Valid 75 1.0 t
CLCL
– 50 ns
11 t
RHDX
Data Hold After RD High 0 0 ns
12 t
RLRH
RD Pulse Width 115 1.0 t
CLCL
– 10 ns
13 t
DVWL
Data Setup to WR Low 42.5 0.5 t
CLCL
– 20
(1)
ns
14 t
WHDX
Data Hold After WR High 115 1.0 t
CLCL
– 10 ns
15 t
DVWH
Data Valid to WR High 125 1.0 t
CLCL
ns
16 t
WLWH
WR Pulse Width 115 1.0 t
CLCL
– 10 ns
Table 26-8. External Data Memory Characteristics, V
CC
= 4.5 - 5.5 Volts, 1 Cycle Wait-state
Symbol Parameter
8 MHz Oscillator Variable Oscillator
Unit
Min. Max. Min. Max.
01/t
CLCL
Oscillator Frequency 0.0 16 MHz
10 t
RLDV
Read Low to Data Valid 200 2.0 t
CLCL
– 50 ns
12 t
RLRH
RD Pulse Width 240 2.0 t
CLCL
– 10 ns
15 t
DVWH
Data Valid to WR High 240 2.0 t
CLCL
ns
16 t
WLWH
WR Pulse Width 240 2.0 t
CLCL
– 10 ns
