Page #37 background image
37
AT90S2313
0839G–08/01
In PWM mode, the Timer Overflow Flag1 (TOV1) is set when the counter advances from
$0000. Timer Overflow Interrupt1 operates exactly as in normal Timer/Counter mode
(i.e., it is executed when TOV1 is set, provided that Timer Overflow Interrupt1 and global
interrupts are enabled). This also applies to the Timer Output Compare1 flag and
interrupt.
Table 13. PWM Outputs OCR = $0000 or TOP
COM1A1 COM1A0 OCR1A Output OC1
1 0 $0000 L
10TOPH
1 1 $0000 H
11TOPL
