OPERATOR AND SAFETY MANUAL
1NO0031EN-08
CX 12 - CX 15
11
MODEL
CX12
CX15
Max. working height
12 m
15 m
Max. floor height
10 m
13 m
Min. floor height
1.59 m
1.80 m
Weight (empty)
6,900 kg
7,300 kg
Platform length
Extensions retracted
4.80 m
Extensions deployed
7.30 m
Platform width
2.22 m
Course of deck extensions
1.25 m
Max. number of occupants
On the platform
6
On a deck extension
2
Overall rated load
1,100 kg
700 kg
Max. Load on deck extension
230 kg
Max. wind speed
12.5 m/s (45 km/h)
Max. manual force
400 Newton
Max. tilt on wheels
Side slope
Longitudinal slope
Max. tilt on outriggers
Side slope
Longitudinal slope
Max. gradeability
45%
Overall length
4.86 m
Overall width
2.30 m
Overall height
Guardrails up
2.78 m
2.99 m
Guardrails folded
2.02 m
2.23 m
Wheelbase
2.90 m
Ground clearance
0.36 m
Oscillating axle travel
0.20 m
Drive wheels
4
Steering wheels
2
Tyres (solid)
33x12x20
Turning radius
Inside
2.50 m
Outside
5.60 m
Travel speed
Transport position
6 km/h
Platform elevated
0.85km/h
Elevation speed
Raising
50 s
Lowering
50 s
Levelling capacity (outriggers)
Side to side
9.4° (16.5%)
Front to back
5.5° (9.6%)
Ground load on one
wheel (*)
Force
3930 daN
Contact pressure
11.7 kg/cm² (1,148 kPa)
Ground load on one outrigger
(*)
Force
3670 daN
Contact pressure
7.0 kg/cm² (787 kPa)
(*): The ground load values indicated may vary depending on the configuration/position of the
machine. An adequate safety margin should always be considered with regard to these values.
The total value of the vibrations to which the hand-arm system is exposed does not exceed 2.5m/s².
The average maximum quadratic value weighted by the acceleration frequency to which the whole
body is exposed does not exceed 0.5m/s².
Due to constant improvements made to its products, ATN Platforms reserves the right to modify their
specifications and equipment without prior notice.
