OPERATOR AND SAFETY MANUAL
1NO0031EN-08
CX 12 - CX 15
16
2.5. FALL HAZARDS
• It is recommended that all persons on the work platform wear a safety
harness with a lanyard attached to a lanyard anchorage point
provided on the work platform. Attach only one harness per lanyard
anchorage point.
• Prior to operation, ensure that all guardrails are correctly installed and locked. Check that
access gates close and lock properly.
• Keep both feet firmly positioned on the platform deck at all times. Never sit or climb on the
guardrails. Never position a ladder or other objects on the platform to provide additional
reach.
• When elevated, never attempt to exit the platform using the lift structure.
• Do not attempt to exit or access the aerial work platform until it is in stowed position and the
outriggers have been retracted.
• Keep all mud, grease and other slippery substances from footwear, steps and platform deck.
• Always face the machine when entering or leaving the aerial work platform. Always maintain
a 3-point contact with the machine, using two hands and one foot or two feet and one hand at
all times.
2.6. OPERATING LIMITS
Model
CX12
CX15
Max. floor height
10 m
13 m
Max. working height
12 m
15 m
Maximum number of platform occupants
6
Maximum platform load (distributed)
1,100 kg
700 kg
Maximum number of occupants on a deck
extension
2
Maximum deck extension load (distributed)
230 kg
Maximum wind speed
12.5 m/s (45 km/h)
Maximum manual force
400 Newton
Max. tilt on wheels
Side to side
3 degrees
2 degrees
Front to back
3 degrees
Max. tilt on outriggers
Side to side
1 degree
Front to back
2 degrees
Max. gradeability (See Note)
45%
Operating temperature
-20 … +60°C
-NOTE-
Do not operate the engine more than 10 minutes with a slope or grade exceeding of 35%.
