Notes:
J: At each start-up or each operator change.
(1): After every 50 hours of operation.
(2): At the interval indicated or every 2 years.
(3): At the interval indicated or every year.
(4): The air filter body is equipped with a clogging indicator. Clean the filter if the indicator is red
before the indicated interval.
(5) The oil level must show in the oil level window.
7.4. WHEELS
The wheel lug nuts should be tightened after the
first 50 hours of use and then every 3 months or
100 hours of operation thereafter.
• Wheel replacement
To ensure the machine stability is not impaired, the wheels must only be replaced with
wheels of identical characteristics (dimensions, load-carrying capacity, deflection under load,
web position, weight, etc.).
The lug nuts must be tightened to the appropriate torque to prevent a wheel getting loose. A
torque wrench must be used to tighten the lug nuts. Excessive tightening of the nuts can
result in the rupture of the wheel lugs or deformation of the threads.
• Tightening wheels
1- Install all the nuts by hand. Do not lubricate the threads.
2- Tighten the lug nuts in turn, respecting the order and tightening steps indicated below:
