7.6. FACTORY SETTINGS
MOVEMENT SPEED / DURATION SETTING
NOTES:
The hydraulic oil temperature must be above 25°C
Record the duration of the movement with a person in the work platform
STRUCTURE MOVEMENTS:
Values in seconds
Values in mA
Elevation movement
45 to 55
Refer to the IQAN "default values" page
Lowering movement
45 to 55
Refer to the IQAN "default values" page
Extension out (Option)
9 to 11
Refer to the IQAN "default values" page
Extension in (Option)
9 to 11
Refer to the IQAN "default values" page
MOVEMENT WITH THE PLATFORM OUTSIDE THE TRANSPORT POSITION:
NOTE:
Take the reading with the "machine started"
Values in seconds
Values in mA
Platform raised forward movement over 10
metres
42 to 45
Refer to the IQAN "default values" page
Platform raised forward movement over 10
metres
42 to 45
Refer to the IQAN "default values" page
SETTING THE FAST MOVEMENT SPEEDS
NOTES:
The hydraulic oil temperature must be above 25°C
Record the duration of the movement with a person on the work platform,
"machine started"
Values in seconds
Values in mA
"Low speed" forward movement (*) over 10
metres
30 to 40
Refer to the IQAN "default values" page
"Low speed" reverse movement (*) over 10
metres
30 to 40
Refer to the IQAN "default values" page
(*): platform in low position
"Slope speed" forward movement over 25
metres
25 to 35
Refer to the IQAN "default values" page
"Slope speed" reverse movement over 25
metres
25 to 35
Refer to the IQAN "default values" page
"High speed" forward movement over 50
metres
33 to 26
Refer to the IQAN "default values" page
"High speed" reverse movement over 50
metres
33 to 26
Refer to the IQAN "default values" page
