ATN CX 12 - Features - Dimensions

OPERATOR AND SAFETY MANUAL
1NO0031EN-08
CX 12 - CX 15
9
1.2. FEATURES - DIMENSIONS
POSITION TRANSPORT
CAPACITE DE MISE A NIVEAU LONGITUDINALE
5.5°
1.25
26°
15°
4.86
4.80
1.59
1.25
GARDE-CORPS RABATTUS
2.02
EXTENSIONS SORTIES
7.30
2.30
2.22
2.78
CAPACITE DE MISE A NIVEAU TRANSVERSALE
9.4°
1.00 2.90
0.36
Modèle
CX12
Dimensions
en mètres (m)
0.96
POSITION HAUTE
10.00
GUARDRAILS FOLDED
HIGH POSITION
DECK EXTENSIONS DEPLOYED
TRANSPORT POSITION
LEVELLING CAPACITY – FRONT TO BACK
LEVELLING CAPACITY – SIDE TO SIDE
Model
CX12
Dimensions in
metres (m)
