ATN Zebra 12 Operator's And Safety Manual

OPERATOR’S AND SAFETY MANUAL
1NO0039UK-00
Zebra 12
58
GROUND CONTROL STATUS (F3).
1- Entry parameters - Structure orientation.
2- Entry parameters – Jib 2
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
Proportional valve control value
The arrows light up when the corresponding movement is controlled.
Status light – Structure position sensor (the light is on when the jib is
between the rear wheels).
The arrows light up when the corresponding movement is controlled.
Status light – Structure position sensor (the light is on when the jib is
between the rear wheels).
Proportional valve control value
