Atronic Harmony - CASHBOX EXCHANGE

26
February 2006
Harmony™ Operating Manual
CASHBOX EXCHANGE
Follow these procedure to exchange or remove the
bill cashbox (stacker box).
1. Unlock the hopper drawer lock and leave the hopper
drawer lock unlocked. Do not remove the key.
2. Slide the coin bowl to the left (fig. a).
3. Depress the cashbox release lever and take the
cashbox out (fig. B).
4. Install an empty cashbox.
5. Slide the coin bowl back to the right, lock the hop-
per drawer and remove the key.
Note:
Casino rules for bill handling may add additional tasks.
MACHINE HANDLING
Figure a
Figure b
