4.4.1 'File' menu
¾ Loading a configuration
This command enables a previously saved configuration file to be opened to load it into the memory. If an
encoder is connected, the loaded configuration will be sent to it.
¾ Save
This command enables the current configuration to be saved in the current file. If no file has previously been
loaded in the memory, it is equivalent to 'Save as'.
¾ Save as
This command enables the current configuration to be saved in a file chosen by the user.
¾ Configure the printer
This command enables the printer configuration and selection window, which will be used for all printing, to be
accessed.
¾ Print the configuration
This command enables the current configuration to be printed on the default selected printer.
4.4.2 'Tools' menu
It enables the encoder and software configuration functions to be accessed.
¾ Receive the configuration
This command enables the serial port connected encoder configuration to be loaded in the memory. Contents of
the frames transmitted by the encoder are displayed for any possible control. When loading is completed, click
on 'Close' to finish the operation.
¾ Send the configuration
This command enables the configuration which is presently in the memory to be sent to the encoder. When this
command is activated, a window enables a choice of the parameters to be sent. By default, those modified
since the last update are validated.
