5. If you also want to change the monitor source setting (see
Appendix C), you may want to do it now while the case is open.
6. Turn the chassis assembly over and reassemble it into the inverted
case top. Make sure that the front and rear panel edges go into
their slots in the case.
Option Filter
Socket 2 (AUX2
Option Filter
Socket 1 (AUX1)
REAR OF UNIT
RIGHT SIDE
Figure B-2. Location and Orientation of Option Filters
B
Option Filters
Appendix B - Option Filter Installation
Portable One Plus Access User's Manual B-3
