Gen Load Function
Measurement Range
<1 Ω to 20 kΩ
Accuracy
±[5 % + 0.5 Ω] for readings <1 kΩ
Degrades rapidly above 1 kΩ or with
reactive loads
Frequency Range
20 Hz to 20 kHz
Test Voltage
200 mV default. Usable from 10 mV to
generator maximum
Wow & Flutter Function
Test Signal Compatibility
2.80 kHz to 3.35 kHz
Measurement Range
<0.005% to 3% (single range)
Accuracy (4 Hz)
±(5% of reading + 0.002%)
Detection Modes IEC/DIN (quasi-peak per IEC-386),
NAB (average),
JIS (per JIS 5551)
Response Selections
Weighted 4 Hz bandpass per IEC/DIN/NAB
Unweighted
0.5 Hz-200 Hz
Residual W+F
Weighted
≤0.005%
Unweighted
≤0.01%
Minimum Input
25 mV
Settling Time
IEC/DIN or NAB Typically 3 to 6 seconds
JIS
Typically 15 to 20 seconds
G
Specifications
Appendix G - Specifications
Portable One Plus Access User's Manual G-7
