AUXILIARY SIGNALS
Analog Sync Output LSTTL compatible signal that is intended to
be used as a trigger for stable oscilloscope
displays.
Input Monitor
Buffered version of the analog or digital
input signal. Amplitude is typically 0 to
2.83 Vpp.
Reading Monitor
Buffered version of the analog or digital
analyzer output signal after all filtering and
gain stages. Amplitude is typically 0 to
2.83 Vpp.
AUDIO MONITOR
Power Output Typically 1 Watt
G Specifications
Appendix G - Specifications
G-8 Portable One Plus Access User's Manual
