17
General purpose output terminals (GPO)
Pin
number
Signal name Explanation
Terminal
color
32 GPO0 General purpose output terminal 0
Black
33 GPO1 General purpose output terminal 1
34 GPO2 General purpose output terminal 2
35 GPO3 General purpose output terminal 3
36 GPO4 General purpose output terminal 4
37 GPO5 General purpose output terminal 5
38 GPO6 General purpose output terminal 6
39 GPO7 General purpose output terminal 7
• You can assign functions to the general purpose input/output terminals (GPI and GPO) on the web remote’s settings screen.
Audio-Technica LINK terminal
Connect the Audio-Technica products and configure the system.
NOTICE
• Power is supplied to external devices from the 5 V pin (22); however this pin has a maximum rating of +5 VDC at 100 mA. When you
use this, select a circuit or current limit (resistance value) so that the rating is not exceeded.
• If this is used beyond its ratings, it may cause the product to malfunction, but even more so, it may cause fires or unforeseen
accidents.
