Page #83 background imageLoading...
Page #83 background image
83
ATUC-IRDU specifications
General specifications
Interpretation format Infrared
Frequency 1MHz - 10 MHz
Modulation method FM
Wavelength 870nm
Range Max. 6m
I/O connector
Inputs Microphone jack
Outputs Headphone jack×2
Frequency response +1.0, -2.0dB, 200Hz - 5kHz (+4dBu output at 1kHz)
Dynamic range 65dB, A-Weighted
Signal-to-noise ratio 58dB, A-Weighted
Headroom 7dB
Equivalent input noise Less than –80dBu, Rs = 150ohm
Total harmonic distortion Less than 1%, 1kHz unity
Phantom power supply DC+24V
Battery LI-240a (lithium-ion battery) × 2
Battery life
1 battery 6hours 40minutes (transmitting:receiving = 1:4)
2 batteries 13hours 20minutes (transmitting:receiving = 1:4)
Power supply DC+12V, 1A
Power consumption 4.0W
Operation guaranteed temperature range 0 - 40°C
Operation guaranteed humidity range 25 - 85%
External dimensions (W × D × H) 189mm × 150mm × 71.3mm
Weight Approx. 800g (including 2batteries)
Finish
Front panel Gunmetal
Enclosure Black
Included Accessories Battery cover × 2
Input/output specifications
Analog input specifications
Input Terminals Gain
Load
Impedance
Input Level
Connector
Balanced/
Unbalanced
Minimum Nominal Maximum
MIC Input 7 - 47dB 5k ohm –60dBu –40dBu –20dBu XLR female Balanced
Analog output specifications
Output Terminals Load Impedance
Output Level
Connector
Minimum Nominal Maximum
Headphones 32ohm - 1.5mW 15mW φ3.5-mm stereo
Speaker 8ohm - 50mW 100mW -
