Input/output specifications
Analog input specifications
Input Terminals Gain
Load
Impedance
Input Level
Connector
Balanced/
Unbalanced
Minimum Unity Maximum
MIC/LINE
Input 1-2
Mic 15-59dB 5k ohm –60dBu –40dBu –16dBu Euroblock Balanced
Line 15-59dB 20k ohm –40dBu
+4dBu*/
0dBu
+24dBu*/
+20dBu
Euroblock Balanced
AUX Input LR (Mono ×2) - 10k ohm -
0dBV*/
–10dBV/
–20dBV
+20dBV*/
+10dBV/
0dBV
RCA Pin Unbalanced
INTERPRETATION
RETURN 1-2
- 20k ohm -
+4dBu*/
0dBu
+24dBu*/
+20dBu
Euroblock Balanced
* Default setting
Analog output specifications
Output Terminals Load Impedance
Output Level
Connector
Balanced/
Unbalanced
Minimum Unity Maximum
BAL. (Balanced) Output 1-4 150ohm - +4dBu +24dBu RCA Pin Balanced
UNBAL. (Unbalanced)
Output 1
300ohm - 0dBV +20dBV Euroblock Unbalanced
Digital input/output specifications
Terminals Format
Data length/Sampling
Frequency
Audio Connector
USB USB 24bit/48kHz Playback: MP3 or WAV/Record: MP3 or WAV USB (A type)
DU CHAIN A/B (C/D) Original format 24bit/48kHz Floor, Return, Interpretation language, Active Mic RJ-45
CU LINK A/B Original format 24bit/48kHz Floor, Return, Interpretation language, Active Mic RJ-45
Control I/O specifications
Terminals Format Level Connector
NETWORK IEEE802.3 10BASE-T/100BASE-TX RJ-45

Audio Technica ATUC-M43H Specifications

General

Brand	Audio Technica
Model	ATUC-M43H
Category	Conference System
Language	English
