ATUC-50IU specifications
General specifications
I/O connector
Inputs
Euroblock connector: microphone input terminal × 1 set, operation input
terminal × 6 sets, and general purpose input terminal (GPI) × 8 sets
Outputs
Euroblock connector: speaker output terminal × 1 set, headphone output
terminal × 1 set, status output terminal × 6 sets, power supply terminal × 1 set,
general output terminals (GPO) × 8
CHAIN DU/CU connection terminals
Data length/Sampling frequency 24bit/48kHz
Frequency response +1.0 - 2.0 dB, 20 Hz - 20 kHz (+4 dBu output at 1 kHz)
Dynamic range 106 dB, A-Weighted
S/N ratio 86 dB, A-Weighted
Headroom 20 dB
Noise equivalent input Less than –125 dBu, Rs = 150 Ω
Total harmonic distortion Less than 0.07%, 1 kHz unity
Phantom Power DC+48V
Power requirement DC+48V
Power Consumption 3.4 W
Operation guaranteed temperature range 0 - 40°C
Operation guaranteed humidity range 25 - 85%
External dimensions (W × D × H) 116 mm × 173 mm × 25 mm
Weight 460g
Included Accessories
Quick Start Guide, Euroblock connecters × 13 (green × 3, black × 10),
warranty
