78
ATLK-EXT165 specifications
General specifications
I/O connector
LINK POWER STATUS Euroblock connector (3 pins)
CHAIN DU/CU connecter terminals (RJ-45 × 2)
Power supply 100 - 240 VAC, 50/60 Hz
Power Consumption 15 - 160 W (max.); 50 ATUC-50DUs is equivalent to 2.55 A
Operation guaranteed temperature range 0 - 40 °C
Operation guaranteed humidity range 25 - 85%
External dimensions (W × D × H) 217 mm × 326 mm × 41mm
Weight 2.2 kg
Included Accessories Quick Start Guide, Euroblock connector × 1 (black), table mount, warranty
ATUC-VU specifications
General specifications
Power supply DC+5V (supplied from DUa)
Power consumption Max. 240 mA
Compatible NFC MIFARE
Operation guaranteed temperature range 0 - 40 °C
Operation guaranteed humidity range 25 - 85%
External dimensions (W × D × H) 150 mm × 67 mm × 20mm
Cable length 420 mm
Weight 105 g (including cable)
