74
ATUC-50DU/DUa/INT specifications
General specifications
I/O connectors
Inputs Microphone jack×1
Outputs Headphone jack×1
CHAIN DU/CU connection terminals
Sampling frequency 24bit/48kHz
Frequency response +1.0, –2.0dB 20Hz - 20kHz, refer to +4dBu output @1kHz.
Dynamic range 107dB A-Weighted
Signal to noise 87dB A-Weighted
Headroom 20dB
Equivalent input noise Less than –121dBu Rs=150ohm
Total harmonic distortion Less than 0.07% 1kHz unity
Phantom power DC+24V
Power requirement DC+48V
Power consumption 2.2W
Operation guaranteed temperature range 0-40°C
Operation guaranteed humidity range 25-85%
External dimensions (W × D × H) 135mm × 148.3mm × 84.2mm
Net Weight 570g (900g including the optional bottom weight)
Finish
Top panel Gun metal
Enclosure Black
Included Accessories Quick Setup Guide, Warranty
