53
Redundant Audio
SECONDARY PRIMARY
SECONDARY PRIMARY
In redundant audio mode, independent networks for both the primary and secondary are needed.
If a fault occurs, for whatever reason, on the Dante primary side network, the system automatically switches to the Dante audio on the
secondary network.
Split
SECONDARYPRIMARY
In split audio mode, independent networks for both the primary and secondary are needed.
The primary is the IRCU external control terminal and the secondary is the Dante audio terminal.
IRCU Dante channel list
No Dante transmission channel Dante Receiving channel
1 Active Mic 1 Mic/Line 1
2 Active Mic 2 Mic/Line 2
3 Active Mic 3 Aux L
4 Active Mic 4 Aux R
5 Active Mic 5 Language1-1
6 Active Mic 6 Language1-2
7 Active Mic 7 Language2-1
8 Active Mic 8 Language2-2
9 Active Mic 9 Language3-1
10 Active Mic 10 Langauge3-2
