USER'S MANUAL
bit One HD /
Remark: the output channels are 13 in total.
The sum of the analog and digital outputs
(AD Link) must not exceed the number of
available channels.
5.7.3. OUTPUT TO AN AMPLIFIERS SYSTEM PROVIDED WITH AD LINK AND AC LINK CONNECTIONS
(THESIS TH) AND AMPLIFIERS PROVIDED WITH PRE INPUT (see section 7.3.12 - 7.4.12 - 7.5.5).
5.7.2. OUTPUT TO AN AMPLIFIERS SYSTEM WITH PRE INPUT
AV Amplier
CH9 ÷ CH12CH5 ÷ CH8CH1 ÷ CH4 CH13
CH1÷CH4
CH5÷CH8 CH9÷CH13
