13. Technical data
Information
The following tables include standard and optional features. For detailed information
on the customer-specific version, refer to the order-related data sheet.The technical
data sheet can be downloaded from the Internet in both German and English at ht-
tp://www.auma.com (please state the order number).
13.1. Technical data Multi-turn actuators
Features and functions
Short-time duty S2 - 15 min, classes A and B according to EN 15714-2Standard:Type of duty
(Multi-turn actuators for open-close
duty)
Short-time duty S2 - 30 min, classes A and B according to EN 15714-2Option:
For 100 % nominal voltage and +40 °C ambient temperature and at run torque load at maximum output
speed.
Intermittent duty S4 - 25 %, class C according to EN 15714-2Standard:Type of duty
(Multi-turn actuators for modulating
duty)
Intermittent duty S4 - 50 %, class C according to EN 15714-2Option:
For 100 % nominal voltage and +40 °C ambient temperature and at modulating torque load.
3-phase AC asynchronous motor, type IM B9 according to IEC 60034-7, IC410 cooling procedure ac-
cording to IEC 60034-6
Motors
Refer to name plate of ACV actuator controls
Permissible variation of mains voltage: ±10 %
Permissible variation of mains frequency: ±5 %
Mains voltage, mains frequency
Category III according to IEC 60364-4-443Overvoltage category
F, tropicalizedStandard:Insulation class
H, tropicalizedOption:
Thermoswitches (NC)Motor protection
Self-locking: Speed ranges 6 – 60 rpm and 12 – 120 rpm
NOT self-locking: Speed range variant 24 – 240 rpm
Applications of NON self-locking speed variants with pulling loads (like protective weirs, fishbelly flap
gates and sluice gates, etc.) on request.
Self-locking
Multi-turn actuators are self-locking if the valve position cannot be changed from standstill while torque
acts upon the output drive.
110 – 120 V AC, 220 – 240 V AC or 380 – 480 V ACVoltages:Motor heater (option)
Power depending on the size 12.5 – 25 W
Manual drive for setting and emergency operation, handwheel does not rotate during electrical operation.Manual operation
Handwheel lockable
Handwheel stem extension
Power tool for emergency operation with square 30 mm or 50 mm
Option:
Indication whether manual operation is active/not active via single switch (1 change-over contact)Indication for manual operation (op-
tion)
AUMA plug/socket connector with screw-type connectionStandard:Electrical connection
Terminals or crimp connection
Gold-plated control plug (sockets and plugs)
Option:
Metric threadsStandard:Threads for cable entries
Pg-threads, NPT-threads, G-threadsOption:
Terminal plan according to order number enclosed with deliveryTerminal plan
B1 according to EN ISO 5210Standard:Valve attachment
A, B2, B3, B4 according to EN ISO 5210
A, B, D, E according to DIN 3210
C according to DIN 3338
Option:
Special valve attachments: AF, AK, AG, B3D, ED, DD, IB1, IB3
A prepared for permanent lubrication of stem
74
SAV 07.2 – SAV 16.2 / SARV 07.2 – SARV 16.2 Control unit: electronic (MWG)
Technical data ACV 01.2 Modbus TCP/IP
