Spare parts list
45
Please state device type and our order number (see name tag) when ordering
spare parts. Only original AUMA spare parts should be used. Failure to use original
spare parts voids the warranty and exempts AUMA from any liability. Delivered
spare parts may slightly vary from the representation in this manual.
Ref. no. Designation Type
005.0 Drive shaft Sub-assembly
005.1 Motor coupling Sub-assembly
005.3 Manual drive coupling Sub-assembly
009.0 Manual gearing Sub-assembly
019.0 Crown wheel Sub-assembly
023.0 Output drive wheel for limit switches Sub-assembly
024.0 Drive wheel for limit switches Sub-assembly
025.0 Locking plate Sub-assembly
058.0 Cable for protective earth Sub-assembly
070.0 Motor (incl. ref. no. 079.0) Sub-assembly
079.0 Planetary gearing for motor drive Sub-assembly
155.0 Reduction gearing Sub-assembly
500.0 Cover Sub-assembly
502.0 Pin carrier without pins Sub-assembly
505.0 Pin for controls Sub-assembly
506.0 Pin for motor Sub-assembly
525.0 Coupling Sub-assembly
528.0 Terminal frame (without terminals) Sub-assembly
533.0 Terminals for motor/controls Sub-assembly
539.0 Screw plug Sub-assembly
541.0 Ground connection Sub-assembly
553.0 Mechanical position indicator Sub-assembly
554.0
Socket carrier for motor plug & socket
connector with cable harness
-
556.0 Potentiometer as position transmitter Sub-assembly
556.1 Potentiometer without slip clutch Sub-assembly
557.0 Heater Sub-assembly
Ref. no. Designation Type
558.0
Blinker transmitter including pins at
wires (without impulse disc and insula-
tion plate)
Sub-assembly
559.0-1
Electromechanical control unit with
switches, including torque switching
heads
Sub-assembly
559.0-2
Electronic control unit with magnetic
limit and torrque transmitter (MWG)
Sub-assembly
560.0-1 Switch stack for direction OPEN Sub-assembly
560.0-2 Switch stack for direction CLOSE Sub-assembly
560.1 Switch for limit/torque Sub-assembly
560.2-1 Switch case for direction OPEN -
560.2-2 Switch case for direction CLOSE -
566.0 RWG position transmitter Sub-assembly
566.1
Potentiometer for RWG without slip
clutch
Sub-assembly
566.2 Position transmitter board for RWG Sub-assembly
566.3 Cable set for RWG Sub-assembly
567.1 Slip clutch for potentiometer Sub-assembly
573.0
Ex plug & socket connector with termi-
nal blocks (KES)
Sub-assembly
583.0 Motor coupling on motor shaft Sub-assembly
596.0 Output drive flange with end stop Sub-assembly
607.0 Cover Sub-assembly
612.0 Screw plug for end stop Sub-assembly
614.0 EWG position transmitter Sub-assembly
627.0 MWG cover 05.3 -
629.0 Pinion shaft Sub-assembly
S1 Seal kit, small Set
S2 Seal kit, large Set
