AUMA SQEx 12.2 Manual

Short description
7
2
Short description
Part-turn actuator Definition according to EN 15714-2/EN ISO 5211 or EN ISO 22153/ MSS SP 101:
A part-turn actuator is an actuator which transmits a torque to the valve for less than
one full revolution. It need not be capable of withstanding thrust.
AUMA part-turn actuator
Figure1: AUMA SQEx 10.2 part-turn actuator
[1]
[2]
[3]
[4]
[5]
[1] Motor [2] Electrical connection
[3] Handwheel [4] Valve attachment
[5] Mechanical position indicator
AUMA part-turn actuators SQEx/SQREx are driven by an electric motor. A handwheel
is available for setting and emergency operation.
Controls are required to operate or process the actuator signals.
Actuators without controls can be equipped with AUMA actuator controls at a later
date. For more information, please state our order number. The order number is avail-
able on the tame tag. (Refer to Name tag [}8].)
Switching off in end positions may be either by limit or torque seating.

AUMA SQEx 12.2 Specifications

General

Brand	AUMA
Model	SQEx 12.2
Category	Controller
Language	English
