 Notification Center
View system or app notifications.
2.4 Operating Instructions
2.4.1 Command Stick Description
When using the remote controller for flight control, you need to know the flight operation
of the current remote controller in detail and fly with caution. The command stick modes are
Mode 1, Mode 2 (default), and Mode 3, as shown in Figure 2-9, Figure 2-10, and Figure 2-11.

If you are operating the aircraft for the first time, please keep the fo
rce gentle when
moving the command sticks until you are familiar with the operation.

The flight speed of the aircraft is proportional to the movement of the command stick.
When there are people or obstacles near the aircraft, please don't
move the stick
excessively.

Do not hand over the remote controller to persons who have not learned how to use the
remote controller.
 Mode 1
Figure 2-9 Mode 1
Table 2-8 Mode 1 Details
Stick Move Up/Down Move Left/Right
Left Stick
Control the forward and backward
movement of the aircraft
Control the heading of the aircraft
Right Stick
Control the ascent and descent of
the aircraft
Control the left or right movement of
the aircraft
