Autel EVO Max 4T - Chapter 3 Smart Battery; 3.1 Battery Introduction

32 Chapter 3 Smart Battery
EVO Max 4T User Manual
Chapter 3 Smart Battery
3.1 Battery Introduction
The rechargeable lithium polymer battery used in EVO Max 4T has the characteristics of
high energy density and large capacity. The battery needs to be charged with a special charging
device.
3.1.1 Battery Appearance Introduction
Figure 3-1 Battery Appearance
Table 3-1 Battery Appearance Description
No. Name Description
1
Disassembly
Button
When removing the battery from the aircraft, you need to press
and hold the disassembly buttons on both sides and pull to
remove the battery.
2 Battery Indicator Used to display the current battery level.
3 Power Button
Long press the power button for 3s to turn on or turn off the
battery.
