Chapter 5 First Flight 75
EVO Max 4T User Manual
Figure 5-1 Unpack the outer packaging and take out the rugged case
After taking out the Autel Smart Controller V3 from the rugged case, you can see the EPP
tray packaging, and then you can see the documents, Live Deck 2, battery charger, RC charger,
and accessories after taking it out, as shown in Figure 5-2.
Figure 5-2 Rugged Case
Table 5-2 What's In The Case
No. Item Description
1 Aircraft Please refer to "Chapter 1 Aircraft".
2 Battery
There are 3 smart batteries in total, please refer to "Chapter
3 Smart Battery".
3
Autel Smart
Controller V3
Please refer to "Chapter 2 Remote Controller".
4 EPP Tray Packaging Used to carry the Autel Smart Controller V3.
5 Documentation Quick Start Guide, Service Card.
6 Live Deck 2
Optional accessory: Provide high-definition real-time video to
improve the team's collaborative combat capabilities.
7 Battery Charger
Please use the Autel battery charger to charge the smart
battery.
To Next Page
