*IMPORTANT NOTE: THE NOTES AND MECHANICAL EXECUTIONS IMPLICIT IN THESE
DRAWINGS ARE FOR GUIDANCE PURPOSES ONLY. LOCAL, NATIONAL AND STATE
CODES MUST BE ADHERED TO IN ALL CASES. IT IS IMPORTANT TO USE ONLY
QUALIFIED AND EXPERIENCED INSTALLATION PERSONNEL. AUTOFLAME TECH
CENTRES CAN ADVISE.
UNDER ALL CODES THAT AUTOFLAME ARE AWAR OF, IT IS NOT PERMITTED TO FIT 2
PROBES IN ON EXTERNAL POT.
IF IN DOUBT, PLEASE CONTACT AUTOFLAME.
LEVEL PROBES MOUNTED EXTERNALLY
IN PURPOSED DESIGNED POTS
NON-RETURN
VALVE
AUTOFLAME FEED WATER VALVE CONTROLLED
BY A SERVOMOTOR (OPERATIONAL V.S.D.)
FEED WATER PUMP
AUTOFLAME FEED WATER
TEMP. SENSOR (PT1000)
CAPACITANCE PROBE
OPTIONAL V.S.D. CONTROL
FOR FEED WATER PUMP
FLUE
SAFETY VALVE
AUTOFLAME
PRESSURE
DETECTOR
BOILER HIGH
LIMIT
STEAM NON-RETURN VALVE
STEAM FLOW VALVE/ CROWN VALVE
CAPACITANCE PROBE
AUTOFLAME STEAM TEMP. SENSOR
STEAM BOILER
SIGHT GLASS
HIGH WATER
REQUIRED LEVEL
1st LOW WATER
2nd LOW WATER
