AUTOFLAME Mk7 - Methods of TDS Control

½” Threaded A B C D E F G H I
inches 4 1.22 3.91 4.81 3.56 7.22 2.56 2.36 1.97
mm 102 31 99 122 90 183 65 60 50
A
D
B
C
H
F
E
G
I
3.10.7 Threaded Feed Water Valve
3 Water Level Probes
